Learn about PLC Programming (Digital and Analog), OPC UA, MQTT and Cloud interfacing

What you will learn

PLC Programming with PLCnext

HMI Screen designing

Interfacing external hardware (Raspberry pi) with PLC via OPC UA

Interfacing external software (FACTORY IO) with PLC via OPC UA

Description

    You might have programmed many PLCs, HMI’s, or IIoT devices. But have you ever come across a device that combines all of these in one technology? A device with a Linux operating system inside that allows the user to link other devices via MQTT, OPC UA, HTTP, HTTPS, SFTP, SNTP, etc. In this course, I am introducing an online course on PLCnext AXC F 2132 Controller.

In this course, you will learn not only how to program the PLC and HMI but also how to link IIoT tools like OPC UA, MQTT, and Cloud interfacing using Node-RED. The course has high-quality videos with resources. If you own a PLCnext and do not know where to kick start your training, this course fits best to you.

In this e-Learning course you learn the following:

  1. Introduction to PLCnext- Understanding various elements of PLCnext
  2. Communicating PC with PLCnext via Ethernet using PLCnext Engineering software
  3. Programming Digital and Analog IOs with various examples
  4. Creating an HMI for the PLCnext Digital and Analog IOs with an example
  5. Initializing OPC UA in PLCnext and reading PLC data via UaExpert
  6. Initializing Node-RED in PLCnext – Node-RED is an open-source visualizing platform
  7. Interfacing FACTORY I/O with PLCnext via OPC UA

Once, you finished the course you will get a certificate

English

Language

Content

Introduction to PLCnext AXC F 2132

Welcome

Unboxing PLCnext

Quiz 1

PLCnext – PLC to PC Communication

Quiz 2

PLCnext – Programming with local variables

PLCnext – Programming the Controller External Digital IOs

PLCnext – Programming the Controller External Analog IOs


Get Instant Notification of New Courses on our Telegram channel.


Quiz 3

Initializing HMI in PLCnext

PLCnext – Designing the HMI for Digital IOs

PLCnext – Designing the HMI for Analog Inputs

PLCnext – Designing the HMI for Analog Outputs

PLCnext- Monitoring and controlling HMI in browser

Quiz 4

Interfacing PLCnext with Raspberry pi via OPC UA and MQTT

PLCnext- Activating OPCUA and interfacing with UaExpert

PLCnext- Interfacing Node-RED via OPCUA

PLCnext- Interfacing FACTORY IO via OPCUA

Quiz 5

Course Wrap-up

Podcast with Ira Sharp- Director of Marketing at Phoenix Contact

PLCnext – Presentations

Thank you
